Anti-lock brake circuit, with jl4 for Chevrolet Silverado 1500 (2000-2012)

ABS PUMP MOTOR ABS-1 FUSE 61 FUSE 56 ABS-2 FUSE 9 FUSE 8 AGLE SNS A BLK WIRE BLK/WHT WIRE BRK SNS VEH SPD SIG LOW REF BRN WIRE CAN H GND CAN L B+ GMLAN + GMLAN + LOW REF AGLE SNS B AGLE SNS C RR WHL SNS COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT SIDE OF FRAME ASSEMBLY) GMLAN - GMLAN - PWR BRK H GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT WHEEL SPEED SENSOR (WSS) (ON LEFT FRONT STEERING KNUCKLE) LEFT REAR WHEEL SPEED SENSOR (WSS) (ON LEFT REAR BRAKE BACKING PLATE) LF WHL SNS COMM DATA LOGIC LR WHL SNS LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PPL/WHT WIRE PWR BRK L ANGLE SNS RADIO RED WIRE RED/BLK WIRE RF WHL SNS RIGHT REAR WHEEL SPEED SENSOR (WSS) (ON RIGHT REAR BRAKE BACKING PLATE) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/ LUXURY EDITION W/O LUXURY EDITION EXCEPT 6.6L YEL WIRE YEL/BLK WIRE

12 13 PPL BRK SIG 16 17 19 GMLAN + GMLAN - COMM DATA ABS INDICATOR BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRAKE BOOSTER VACUUM SENSOR (LEFT REAR OF ENGINE COMPT) BRAKE FLUID LEVEL SWITCH (ON MASTER CYLINDER) BRAKE INDICATOR COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE EXCEPT 4.3L, 5.3L (VIN O), 5.3L (VIN 3), 6.0L (VIN K) GRY WIRE GRY/WHT WIRE I/P MULTI-FUNCTION SWITCH INSTRUMENT PANEL CLUSTER (IPC) LOGIC LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PARK BRAKE SWITCH (ON PARK BRAKE PEDAL ASSEMBLY) POWER BRAKE BOOSTER (LEFT REAR OF ENGINE COMPT) PPL PPL/WHT WIRE PRK BRK SW RIGHT FRONT WHEEL SPEED SENSOR (WSS) (ON RIGHT FRONT STEERING KNUCKLE) STEERING ANGLE SENSOR (ON STEERING COLUMN) STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE TRACTION SW YEL WIRE YEL/BLK WIRE
