Chevrolet Silverado 1500 (2000-2012) w/o luxury edition, w/ odometer security provisions Wiring diagram

2 OR MORE OF W/ ONSTAR, AUDIO AMPLIFIER (IF EQUIPPED) (UNDER REAR OF CENTER CONSOLE) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) CHIME MODULE (CENTER OF DASH, BEHIND RADIO) DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) DIGITAL RADIO RECEIVER (BEHIND RIGHT END OF DASH) DIGITAL RADIO RECEIVER (IF EQUIPPED) (BEHIND RIGHT END OF DASH) DIGITAL RADIO, REAR SEAT, DK GRN WIRE DRIVER DOOR LOCK/WINDOW SWITCH DRIVER'S SEAT EARPHONE JACKS RADIO CONTROL GROUND DISTRIBUTION SYSTEM HEATED SEAT CONTROL MODULE (W/ SPO HEATED SEATS) HOT AT ALL TIMES HVAC CONTROL MODULE I/P FUSE BLOCK (LEFT SIDE OF DASH, INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LOW SPD GMLAN SER DATA LOW SPEED GMLAN SERIAL DATA LOW SPEED SERIAL DATA LTR FUSE 53 (EXCEPT 6.6L) FUSE 50 (6.6L) MEMORY SEAT MODULE (W/ INDIVIDUAL FRONT SEAT) (UNDER FRONT OF NOT USED NOT USED PASSENGER DOOR LOCK/WINDOW SWITCH POWER DISTRIBUTION SYSTEM RADIO REAR OBJECT SENSOR CONTROL MODULE (AT REAR CARGO AREA, BEHIND TRIM PANEL) REAR SEAT AUDIO (RSA) CONTROL REAR SEAT AUDIO (RSA) CONTROL (IF EQUIPPED) RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (TOP REAR OF PASSENGER COMPT) RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH) TAN WIRE TAN/BLK WIRE THEFT DETERRENT CONTROL MODULE (TDM) (ON RIGHT SIDE OF STEERING COLUMN) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND CENTER OF DASH) W/ DIGITAL RADIO W/ DIGITAL RADIO, REAR SEAT, ONSTAR, EARPHONE JACKS RADIO CONTROL W/ FRONT SEAT, REMOTE CONTROL W/ INDIVIDUAL FRONT SEAT W/ LUXURY EDITION W/ ONSTAR W/ RADIO PROVISIONS W/ REAR SEAT, EARPHONE JACKS RADIO CONTROL W/ REMOTE KEYLESS ENTRY W/O INDIVIDUAL FRONT SEAT W/O LUXURY EDITION W/O LUXURY EDITION, W/ ODOMETER SECURITY PROVISIONS W/O RADIO PROVISIONS WHT WIRE
