Chevrolet Silverado 1500 (2000-2012) tr sw c sig tfp sw a sig tcc sol valve ctrl pnk Wiring diagram

2-3 SHIFT SOL 3-2 SHIFT SOL 4.3L ACC WAKE UP DATA BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE FUSE 19 GRY WIRE HI SPD GMLAN DATA (-) HI SPD GMLAN DATA (+) HOT AT ALL TIMES HOT W/ RUN/CRANK RELAY ENERGIZED LEFT I/P JUNCTION BLOCK LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MISC-IGN FUSE 43 ORG/ WIRE ORG/BLK WIRE P/N PARK/NEUTRAL POSITION (PNP) SWITCH (ON LEFT REAR SIDE OF TRANSMISSION) PNK PNK PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL/WHT WIRE RED/WHT WIRE REPLICATED TOS SIG HI SPD GMLAN DATA (-) HI SPD GMLAN DATA (+) STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCM- BATT FUSE 14 TFP SW B SIG LOW REF TR SW B SIG TFT SENS SIG TR SW A SIG LOW REF IGN 1 VOLT BATTERY TFP SW C SIG TR SW C SIG TFP SW A SIG TCC SOL VALVE CTRL PNK WIRE TR SW P SIG PC SOL HI VSS HI SIG BRK SW SIGN TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON TRANSMISSION TAILSHAFT HOUSING) VSS LOW PC SOL LOW W/O WHT WIRE YEL WIRE YEL/BLK WIRE
