Chevrolet Silverado 1500 (2000-2012) right engine cooling fan resistor Wiring diagram
This page shows the only wiring diagram for the component.right engine cooling fan resistor, which is found in the car Chevrolet Silverado 1500 (2000-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right engine cooling fan resistor (1 of 1)
AUXILIARY FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FAN 1 FUSE
FAN CNTRL RELAY
FAN HI RELAY
FAN LO RELAY
FAN MID 1 RELAY
FAN MID 2 RELAY
FAN-2 FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT AIR TEMPERATURE ACTUATOR (BOTTOM LEFT OF HVAC MODULE)
LEFT ENGINE COOLING FAN
LEFT ENGINE COOLING FAN RESISTOR
LOGIC
LOWER LEFT AIR TEMPERATURE SENSOR (LEFT SIDE OF HVAC MODULE)
LOWER RIGHT AIR TEMPERATURE SENSOR (LOWER LEFT OF HVAC MODULE)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MODE ACTUATOR (LEFT END OF HVAC MODULE)
PNK WIRE
PPL
RECIRCULATION ACTUATOR (TOP RIGHT SIDE OF HVAC MODULE) LOGIC
RIGHT AIR TEMPERATURE ACTUATOR (TOP MIDDLE OF HVAC MODULE)
RIGHT COOLING FAN (RIGHT FRONT OF ENGINE COMPT)
RIGHT ENGINE COOLING FAN RESISTOR
TAN WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, hybrid (3 of 3) -> RIGHT ENGINE COOLING FAN RESISTOR
