Chevrolet Silverado 1500 (2000-2012) power navigation distribution system system Wiring diagram
This page shows the only wiring diagram for the component.power navigation distribution system system, which is found in the car Chevrolet Silverado 1500 (2000-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power navigation distribution system system (1 of 1)
12 2 PNK WIRE
3 2 6 11 LED SIG LED SIG VOLT SIG
AUTOMATIC
AUTOMATIC PNK DAY/NIGHT MIRROR WIRE
AUX HVAC IGN FUSE 45 FUSE 48
BACKUP
BLK WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
BRN/WHT WIRE
DAY/NIGHT
DK BLU WIRE
DK GRN/WHT WIRE
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER OUTSIDE REARVIEW MIRROR (W/ POWER FOLDING MIRROR)
EXCEPT 4.3L 4.3L 6.6L EXCEPT 6.6L
GREEN LIGHT
GRY WIRE
GRY/BLK WIRE
GRY/DK BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF DASH,
IGN 1
INSIDE REARVIEW MIRROR (ISRVM)
LED SIG
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
LIGHT
LOGIC
LOW REF
LT GRN/BLK WIRE
MIRR SIG
MIRROR
MIRROR DISPLAY
ONSTAR BUTTON ASSEMBLY
ONSTAR SW EMERGENCY SW
PNK 4 9 WIRE
PNK WIRE
POWER NAVIGATION DISTRIBUTION SYSTEM SYSTEM
RED WIRE
RLY
RUN/CRANK RLY
RUN/CRNK RELAY
SELECTOR SWITCH
TELE- PHONE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND CENTER OF DASH)
VIDEO SIG
W/ COMFORT, DECOR LEVEL 3 CONVIENCE PACKAGE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> POWER NAVIGATION DISTRIBUTION SYSTEM SYSTEM
