Chevrolet Silverado 1500 (2000-2012) pnk low ref low ref low ref low ref Wiring diagram
This page shows the only wiring diagram for the component.pnk low ref low ref low ref low ref, which is found in the car Chevrolet Silverado 1500 (2000-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk low ref low ref low ref low ref (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 CUSHION, BACK HEAT
1 2 3 4 5 6 7 8 B+ GROUND
BACK HEAT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CUSHION TEMP SEAT BACK TEMP BACK HEAT
DK BLU WIRE
DK GRN WIRE
DRIVER BACK HEATED SEAT ELEMENT (IN DRIVER'S SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER'S SEAT CUSHION)
EXCEPT 6.6L 6.6L
FUSE 37 FUSE 34
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HEATED SEAT CONTROL MODULE
HOT AT ALL TIMES
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
LOW HEAT IND HIGH HEAT IND
LOW HEAT IND HIGH HEAT IND LOW SPEED GMLAN
LT BLU WIRE
LT GRN WIRE
MEDIUM HEAT IND BACK, CUSHION HEAT IND
NCA WIRE
PASSENGER BACK HEATED SEAT ELEMENT (IN PASSENGER'S SEAT BACK)
PNK DK PPL WIRE
PNK LOW REF LOW REF LOW REF LOW REF WIRE
PNK WIRE
PPL
RED/WHT WIRE
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Heated seats circuit, without memory (1 of 2) -> PNK LOW REF LOW REF LOW REF LOW REF WIRE
