Chevrolet Silverado 1500 (2000-2012) inadvertant power relay Wiring diagram
This page shows the only wiring diagram for the component.inadvertant power relay, which is found in the car Chevrolet Silverado 1500 (2000-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inadvertant power relay (1 of 1)
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BRN WIRE
CARGO LAMP
CARGO LAMP SWITCH
CARGO LP SW DOME LP SW RT DR JAMB LT DOOR JAMB DOME LP DFT
COURTESY LAMP RELAY
CTSY LP FUSE
CTSY LP RLY LAMP REQUEST
DK BLU WIRE
DK BLU/WHT WIRE
DOME LAMP
DOME LAMP DEFEAT SWITCH
DOME LAMP SWITCH
ENGINE WIRING HARNESS JUNCTION BLOCK (ON LEFT SIDE OF ENGINE COMPT)
FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
GRY WIRE
GRY/BLK WIRE
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
INADVERT RLY
INADVERTANT POWER RELAY
LEFT I/P COURTESY LAMP
LEFT MINI WEDGE (DOOR JAMB SWITCH) RIGHT POWER DOOR LOCK SWITCH
NOT USED NOT USED
ORG/ WIRE
PPL
RIGHT I/P COURTESY LAMP
RIGHT MINI WEDGE (DOOR JAMB SWITCH)
TAN WIRE
UNDERHOOD LAMP ASSEMBLY OFF ON
WHT WIRE
Go to component -> Courtesy lamps circuit, base -> INADVERTANT POWER RELAY
