Chevrolet Silverado 1500 (2000-2012) clutch sw input ground ignition stoplamp sw input Wiring diagram

A/T BLK/WHT WIRE BODY WIRING HARN JUNCTION BLOCK BODY WIRING HARN JUNCTION BLOCK (UNDER LEFT SIDE OF DASH) BODY WIRING HARNESS JUNCTION BLOCK BRAKE FUSE BRN WIRE BRN/WHT WIRE CLUTCH PEDAL POSITION SWITCH (TOP OF CLUTCH PEDAL) CLUTCH SW INPUT GROUND IGNITION STOPLAMP SW INPUT CRUISE CONTROL MODULE (LEFT REAR OF ENGINE COMPT, ON FIREWALL) CRUISE CONTROL SWITCH CRUISE ENGAGE INPUT CRUISE ENGAGE OUT SPEED SENSOR INPUT CRUISE ON INPUT SET/COAST SIG RESUME/ACCEL SIG DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE WIRING HARNESS JUNCTION BLOCK ENGINE WIRING HARNESS JUNCTION BLOCK (LEFT SIDE OF ENGINE COMPT NEAR BATTERY) FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) CRUISE FUSE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN INST CLUSTER SYSTEMS LT BLU WIRE LT BLU/BLK WIRE LT GRN/BLK WIRE M/T A/T M/T PPL NCA WIRE OFF ORG/ WIRE PPL PPL/WHT WIRE RESUME/ACCEL SET/COAST SOUND SYSTEMS SPEED SENSOR OUTPUT STOP LPS FUSE TCC/STOPLAMP SWITCH (TOP OF BRAKE PEDAL) VCM/PCM (LEFT FRONT OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) VSS HIGH VSS LOW WHT WIRE
