Chevrolet Silverado 1500 (2000-2012) b+ gmlan + gmlan + veh spd sig Wiring diagram

12 13 812 7062 PPL BRK SIG 16 17 19 2500 2501 5986 GMLAN + GMLAN - COMM DATA 4.8L, 5.3L (VIN J), 5.3L (VIM M), 6.0L (VIN Y), 6.2L (VIN 8) ABS INDICATOR ABS PUMP MOTOR ABS-1 FUSE 61 ABS-2 FUSE 9 B+ GMLAN + GMLAN + VEH SPD SIG BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRAKE INDICATOR COMM DATA COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT SIDE OF FRAME ASSEMBLY) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) FUEL SYSTEM CONTROL MODULE (FSCM) (UNDER REAR OF VEHICLE) GMLAN - GMLAN + GRY/WHT WIRE HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT WHEEL SPEED SENSOR (WSS) (ON LEFT FRONT STEERING KNUCKLE) LF WHL SNS LOGIC LT BLU WIRE LT BLU/BLK WIRE NCA WIRE ORG/WHT WIRE PARK BRAKE SWITCH (ON PARK BRAKE PEDAL ASSEMBLY) POWER TAKE OFF (PTO) MODULE (OUTSIDE OF RIGHT FRONT CHASSIS FRAME) PPL PRK BRK SW RADIO RED WIRE RED/BLK WIRE RF WHL SNS RIGHT FRONT WHEEL SPEED SENSOR (WSS) (ON RIGHT FRONT STEERING KNUCKLE) STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE VEH SPD SIG W/ LUXURY EDITION W/O LUXURY EDITION EXCEPT 4.3L 4.3L YEL WIRE YEL/BLK WIRE
