Chevrolet Silverado 1500 (2000-2012) 35 26 low ref pos sens sig Wiring diagrams
This page contains all the electrical diagrams for the component. 35 26 low ref pos sens sig, in which he is found in the car Chevrolet Silverado 1500 (2000-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 35 26 low ref pos sens sig (1 of 2)
35 26 LOW REF POS SENS SIG
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CAMSHAFT POSITION (CMP) SENSOR (FRONT OF ENGINE, ABOVE CRANK PULLEY)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUEL INJECTORS (TOP OF LEFT CYLINDER BANK)
FUEL INJECTORS (TOP RIGHT SIDE OF ENGINE)
GRY WIRE
GRY/BLK WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
ORG/BLK WIRE
PNK PNK PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
PPL
PPL/WHT WIRE
TAN GRY WIRE
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.0l vin 5, engine controls circuit (4 of 5) -> 35 26 LOW REF POS SENS SIG
