Chevrolet Silverado 1500 (2000-2012) 1518 1519 1522 1269 rr vert up sw frt vert up sw horz fwd sig recln fwd sig Wiring diagram

1 2 3 4 5 6 6206 2426 2080 LOW REF LOW REF LOW REF PNK WIRE 1066 1065 5286 UP SW SIG FWD SW SIG FWD SIG 1067 1064 DOWN SW SIG RWD SW SIG 1518 1519 1522 1269 RR VERT UP SW FRT VERT UP SW HORZ FWD SIG RECLN FWD SIG 2482 2435 LOW REF LOW REF PNK WIRE ADJUSTABLE PEDALS CIRCUIT COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DOWN DRIVER DOOR LOCK/ WINDOW SWITCH DRIVER MEMORY/HEATED SEAT SWITCH DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT LUMBAR SWITCH EXIT GRY WIRE GRY/BLK WIRE I/P MULTI-FUNCTION SWITCH (W/ ADJUSTABLE PEDAL) LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LH SEAT SIG LOGIC LT BLU WIRE LT GRN WIRE MEMORY SEAT MODULE (UNDER FRONT OF DRIVER'S SEAT) ORG/ WIRE PPL PPL/WHT WIRE RH SEAT SIG RWD RWD SIG SEATS SYSTEM SERIAL DATA SW SIG TAN WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
