Cooling fan circuit, except hybrid for Chevrolet Silverado 1500 HD (2001-2006)

Cooling fan circuit, except hybrid

Get access

BLK WIRE BLU WIRE COOL/ FAN RELAY 1 COOL/ FAN RELAY 2 COOL/ FAN RELAY 3 COOL/FAN FUSE DK (IN FORWARD LAMP HARNESS) GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT COOLING FAN POWERTRAIN CONTROL MODULE (PCM) RIGHT COOLING FAN UNDERHOOD COOLING FAN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) YEL WIRE
