Chevrolet Silverado 1500 HD (2001-2006) window lockout indicator down Wiring diagram

B+ PWR WND LOCKOUT LR SIGNAL B+ PWR WND LOCKOUT RR SIGNAL B+ VOLT BCM CLASS 2 SERIAL DATA BLK WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRN WIRE BRN/WHT WIRE CLASS 2 SERIAL DATA CREW CAB DK BLU WIRE DK GRN WIRE DRIVER DOOR MODULE DRIVER WINDOW DRIVER WINDOW MOTOR FRONT PASSENGER DOOR MODULE FRONT PASSENGER WINDOW MOTOR GROUND GRY/BLK WIRE HOT AT ALL TIMES I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) I/P RELAY BLOCK ILLUMINATION LEFT REAR WINDOW MOTOR LEFT REAR WINDOW SWITCH (CREW CAB ONLY) LOGIC LR WINDOW (CREW CAB) LT BLU WIRE LT DOORS CIRCUIT BREAKER LT GRN WIRE ORG/ WIRE PWR WND LOCKOUT LR SIG PWR WND LOCKOUT RR SIG PWR WND MOTOR LEFT REAR WINDOW LR REAR UP CTRL PWR WND MOTOR LF DOWN CTRL PWR WND MOTOR LF UP CTRL PWR WND MOTOR LR REAR DOWN CTRL PWR WND MOTOR RF DOWN CTRL PWR WND MOTOR RF UP CTRL PWR WND MOTOR RR REAR DOWN CTRL PWR WND MOTOR RR REAR UP CTRL PWR WND SW LR DOWN SIG PWR WND SW LR UP SIG PWR WND SW RR DOWN SIG PWR WND SW RR UP SIG PWR WND SWITCH LR DOWN SIGNAL PWR WND SWITCH LR UP SIGNAL PWR WND SWITCH RR DOWN SIGNAL PWR WND SWITCH RR UP SIGNAL RIGHT REAR WINDOW RIGHT REAR WINDOW MOTOR RIGHT WINDOW SWITCH (CREW CAB ONLY) RR WINDOW (CREW CAB) RT DOORS CIRCUIT BREAKER SPLICE PACK SWITCH POWER TAN WIRE WHT WIRE WINDOW DOWN WINDOW DOWN DN WINDOW LOCKOUT INDICATOR DOWN WINDOW LOCKOUT SWITCH WINDOW PASSENGER WINDOW SWITCH PASSENGER WINDOW UP YEL WIRE
