Chevrolet Silverado 1500 HD (2001-2006) rear object sensor control module Wiring diagram
This page shows the only wiring diagram for the component.rear object sensor control module, which is found in the car Chevrolet Silverado 1500 HD (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear object sensor control module (1 of 1)
AVALANCHE/ ESCALADE EXT
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNT STOP LAMP
DOOR COURTESY LAMP (LEFT REAR)
DOOR COURTESY LAMP (RIGHT REAR)
ELECTRONIC SUSPENSION CONTROL MODULE
ESCALADE EXT
EXC 8.1L W/O CALIF LEV
EXC ESCALADE EXT
HEATED HEATED SEAT SEAT MODULE ELEMENT (LEFT REAR) (LEFT REAR)
HEATED SEAT ELEMENT (RIGHT REAR)
HEATED SEAT MODULE (RIGHT REAR)
IGNITION COIL 1
IGNITION COIL 5
IGNITION IGNITION COIL 2 COIL 6
IGNITION IGNITION COIL 3 COIL 7
IGNITION IGNITION COIL 4 COIL 8
INTAKE AIR TEMPERATURE (IAT)/MASS ENGINE AIRFLOW (MAF) OIL LEVEL SENSOR SWITCH
MEMORY SEAT MODULE (PASSENGER)
MINI WEDGE (DOOR JAMB SWITCH) (LEFT REAR)
MINI WEDGE (DOOR JAMB SWITCH) (RIGHT REAR)
NCA WIRE
PARK/ NEUTRAL POSITION SWITCH
POWERTRAIN CONTROL MODULE
REAR OBJECT SENSOR CONTROL MODULE
REAR PARKING ASSIST DIAGNOSTIC CONNECTOR
REAR WINDOW DEFOGGER GRID
ROOF MEMORY WINDOW BEACON SEAT SWITCH) RELAY MODULE (LEFT REAR)
ROOF MOUNTED BEACON (BLUNT CUT)
WHT WIRE
WINDOW CONTACTOR
WINDOW SWITCH (RIGHT REAR)
Go to component -> Ground distribution circuit (2 of 5) -> REAR OBJECT SENSOR CONTROL MODULE
