Chevrolet Silverado 1500 HD (2001-2006) prnd b cmp ect sig ign inj 2 ctrl inj 6 ctrl Wiring diagram

3-2 SS LOW REF A/C SYSTEM B+ CLS 2 DATA BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BELOW STEERING COLUMN) BRN/WHT WIRE CENTRAL SEQUENTIAL FUEL INJECTION CFAN RLY LO INJ 5 CTRL CKP SIG COOLING FANS SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ENGINE OIL PRESSURE (EOP) SENSOR FUEL INJECTORS FUSE FUSE FUSE GRY WIRE HOT AT ALL TIMES HOT IN ACCY, RUN, START HOT IN RUN, START I/P FUSE BLOCK IGN 0 FUSE INJ 4 CTRL LOW REF LOW REF REF LOW LOW REF SENS GND LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PCMB FUSE PNK PNK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT FRONT OF ENGINE COMPT) PPL PPL PPL PPL/WHT WIRE PRND A BRK SW PRND P CLUTCH SW INJ 1 CTRL INJ 3 CTRL PPL PRND B CMP ECT SIG IGN INJ 2 CTRL INJ 6 CTRL RANGE B RANGE C IGN B+ REF LOW RED WIRE REF LOW GND RLY CTRL GND SENS GND GND SENSOR SIG STARTING SYSTEM TAN WIRE TAN/WHT WIRE UNDERHOOD JUNCTION BLOCK WHT WIRE YEL WIRE YEL/BLK WIRE
