Chevrolet Silverado 1500 HD (2001-2006) pnk i/p mod disable sw sig Wiring diagram
This page shows the only wiring diagram for the component.pnk i/p mod disable sw sig, which is found in the car Chevrolet Silverado 1500 HD (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk i/p mod disable sw sig (1 of 1)
AIR BAG
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLASS 2 SERIAL DATA
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER SEAT BELT SWITCH
FRONT PASSENGER SEAT BELT SWITCH
GRY WIRE
I/P RELAY BLOCK (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
IGN
IGNITION 1 VOLTAGE
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INFLATABLE RESTRAINT PASSENGER PRESENCE SYSTEM SENSOR
INFLATABLE RESTRAINT PASSENGER SEAT BELT TENSION RETRACTOR SENSOR
INSIDE REARVIEW MIRROR INSTRUMENT
INSTRUMENT PANEL CLUSTER
IPC CLASS 2 SERIAL DATA
LEFT INFLATABLE RESTRAINT SEAT POSITION SWITCH
LT BLU WIRE
LT GRN WIRE
MEMORY SYSTEMS
OFF
PASS SEAT BELT TENS LO REF PPS SENS LO REF
PASS SEAT BELT TENS SIG GROUND PPS SENS SIG
PNK 1 2 3 4 5 6 7 WIRE
PNK I/P MOD DISABLE SW SIG WIRE
PPL
RED WIRE
RIGHT INFLATABLE RESTRAINT SEAT POSITION SWITCH
SPLICE PACK
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> PNK I/P MOD DISABLE SW SIG WIRE
