Chevrolet Silverado 1500 HD (2001-2006) back up lamp voltage output Wiring diagram
This page shows the only wiring diagram for the component.back up lamp voltage output, which is found in the car Chevrolet Silverado 1500 HD (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back up lamp voltage output (1 of 1)
10 12 PNK WIRE
16 5 PNK WIRE
8 7 PNK WIRE
AIR TEMP SENSOR
AIRBAG FUSE
AMBIENT PHOTO SENSOR
BACK UP LAMP VOLTAGE OUTPUT
BACK UP VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BODY RELAY BLOCK
COMPASS
COMPUTER DATA LINES SYSTEM
DK GRN/WHT WIRE
DRIVER DOOR MODULE (DDM) (IN DRIVER'S DOOR)
DRIVER OUTSIDE REARVIEW MIRROR
ELECTROCHROMIC MIRROR
EXTERIOR LIGHTS SYSTEM (BACK-UP CIRCUIT)
GROUND
GRY WIRE
HOT IN RUN, START
IGN 3
INSIDE REARVIEW MIRROR
LEFT I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH)
LOW REF
LOW REF MIR SIGNAL
LT GRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR (AT CENTER OF CORE SUPPORT, BEHIND GRILLE)
PNK WIRE
RR LIGHT PHOTO SENSOR
SELECTOR SWITCH
SERIAL DATA
TEMP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Electrochromic mirror circuit -> BACK UP LAMP VOLTAGE OUTPUT
