Chevrolet Silverado 1500 HD (2001-2006) 4 hi ind control diff lock ind control 4 hi ind control pnk Wiring diagram
This page shows the only wiring diagram for the component.4 hi ind control diff lock ind control 4 hi ind control pnk, which is found in the car Chevrolet Silverado 1500 HD (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 hi ind control diff lock ind control 4 hi ind control pnk (1 of 1)
2 HI IND CONTROL
2-HI IND
4 HI IND CONTROL DIFF LOCK IND CONTROL 4 HI IND CONTROL PNK WIRE
4 LO IND CONTROL
4-HI IND
4-LO IND
AUTO
BATTERY (B+)
BLK WIRE
BRN/WHT WIRE
CREW CAB ONLY
DIMMING INPUT
DIMMING RETURN
DK GRN/WHT WIRE
DRL OFF
FOG LAMP RLY CTRL DRL OFF IND CTRL HEADLAMP ON IND CTRL 5 VOLT REF PPL PNK WIRE
FUSE
GRY WIRE
GRY/BLK WIRE
HEADLAMP ON
HEADLAMP SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH)
IND
INST PANEL DIMMING LED DIMMING SUPPLY I/P LAMPS DIM SUPPLY
INSTRUMENT PANEL CLUSTER
LEFT REAR WINDOW SWITCH
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RIGHT REAR WINDOW SWITCH
TAN/BLK WIRE
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND HEADLAMP SWITCH)
TRANSFER CASE SHIFT CONTROL SWITCH
Go to component -> Instrument illumination circuit (1 of 3) -> 4 HI IND CONTROL DIFF LOCK IND CONTROL 4 HI IND CONTROL PNK WIRE
