Chevrolet Silverado 1500 HD (2001-2006) 22 20 5 8 19 class 2 data low ref door ajar sig ctsy lamp power ctsy lamp ctrl Wiring diagram

22 20 5 8 19 CLASS 2 DATA LOW REF DOOR AJAR SIG CTSY LAMP POWER CTSY LAMP CTRL 22 3 18 13 4 CLASS 2 DATA LOW REF DOOR AJAR SIG CTSY LAMP POWER CTSY LAMP CTRL BATTERY B+ CTSY LAMP SUPPLY BATTERY B+ INADVERTENT PWR SUPPLY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRN WIRE CLASS 2 SERIAL DATA CONVENIENCE PACKAGE COMFORT, DECOR LEVEL #3 CTSY LAMP ON SIG DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DOME LAMP SWITCH DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR MODULE (DDM) (IN LEFT FRONT DOOR) FRONT PASSENGER DOOR LATCH ASSEMBLY FRONT PASSENGER DOOR MODULE (FPDM) (IN RIGHT FRONT DOOR) FUSE FUSE GRY/BLK WIRE HEADLAMP SWITCH HOT AT ALL TIMES I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) I/P RELAY BLOCK (NEAR LEFT KICK PANEL) INTERIOR LAMP DEFEAT SWITCH JUNCTION I/P BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) LEFT FRONT DOOR COURTESY LAMP LEFT REAR DOOR LATCH ASSEMBLY (CREW CAB) LF DOOR AJAR SIG CARGO LAMP LOW CTRL RF DOOR AJAR SIG LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE MERCHANDISED PACKAGE LUXURY EDITION ORG/ WIRE PPL PPL INT LAMP DEFEAT SIG RIGHT FRONT DOOR COURTESY LAMP RIGHT REAR DOOR LATCH ASSEMBLY (CREW CAB) RR DOOR AJAR SIG LR DOOR AJAR SIG TAN WIRE WHT WIRE
