Car Wiring Diagrams for Heated seats circuit for Chevrolet Seeker I (2022-2024)

BATT POS VOLT BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY CTRL MODULE LIN BUS 2 BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER BACK SEAT HEATING ELEMENT DRIVER CUSHION SEAT HEATING ELEMENT DRV SEAT BACK HEATING TEMP SIG DRV SEAT BLOWER MOTOR CTRL 1 DRV SEAT HEATING ELEMENT CTRL DRV SEAT HEATING ELEMENT LO REF DRV SEAT HEATING TEMP SIG DRV SEAT HEATING THERMISTOR LO REF GRN/BLU WIRE GRN/VIO WIRE GRY/BLK WIRE HOT AT ALL TIMES NCA WIRE PASS HEATED BACK THERMISTOR LO REF PASS SEAT BACK HEATING TEMP SIG PASS SEAT BLOWER MOTOR CTRL 1 PASS SEAT HEATING ELEMENT CTRL PASS SEAT HEATING ELEMENT LO REF PASS SEAT HEATING TEMP SIG PASS SEAT HEATING THERMISTOR LO REF PASSENGER BACK SEAT HEATING ELEMENT PASSENGER CUSHION SEAT HEATING ELEMENT RED/BLU WIRE RED/GRN WIRE SEAT HEATING CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT) UNDERHOOD FUSE BLOCK VIO/WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL/GRY WIRE

BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER BACK SEAT BLOWER ASSEMBLY DRIVER CUSHION BACK HIGH IND DRIVER CUSHION BACK LOW IND DRIVER CUSHION BACK MEDIUM IND DRIVER CUSHION SEAT BLOWER ASSEMBLY DRIVER CUSHION, BACK SWITCH DRIVER VENTILATION HIGH IND DRIVER VENTILATION LOW IND DRIVER VENTILATION MEDIUM IND DRIVER VENTILATION SWITCH DRV SEAT BLOWER MOTOR CTRL 1 GRN WIRE GRN/VIO WIRE HOT W/ IGNITION MAIN RELAY ENERGIZED HVAC CONTROL MODULE (UNDER CENTER OF DASH) LOGIC NCA WIRE PASS SEAT BLOWER MOTOR CTRL 1 PASSENGER BACK SEAT BLOWER ASSEMBLY PASSENGER CUSHION BACK HIGH IND PASSENGER CUSHION BACK LOW IND PASSENGER CUSHION BACK MEDIUM IND PASSENGER CUSHION SEAT BLOWER ASSEMBLY PASSENGER CUSHION/ BACK SWITCH PASSENGER VENTILATION HIGH IND PASSENGER VENTILATION LOW IND PASSENGER VENTILATION MEDIUM IND PASSENGER VENTILATION SWITCH RUN/CRANK IGN 1 VOLT UNDERHOOD FUSE BLOCK VIO/WHT WIRE
