Car Wiring Diagrams for Cooling fan circuit for Chevrolet Seeker I (2022-2024)

A/C REFRIGERANT PRESS SENS SIG A/C REFRIGERANT PRESSURE SENSOR AMBIENT AIR TEMPERATURE SENS SIG AMBIENT AIR TEMPERATURE SENSOR BATT POS VOLT BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/RED WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FAN HIGH SPEED RLY CTRL COOLING FAN LOW SPEED RLY CTRL DRIVER INFORMATION CENTER DISPLAY ENG COOLANT TEMP SENS SIG ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE IND ENGINE COOLANT TEMPERATURE SENSOR ENGINE CTRL MODULE LIN BUS 1 ENGINE CTRL SENS 5 VOLT REF 1 ENGINE CTRL SENS LOW REF 2 FAN 3 CTRL GRN WIRE GRN/BLK WIRE GRN/VIO WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES INSTRUMENT CLUSTER LIN BUS 1 LOGIC LOW REF (1) LVDS LVDS BK INFOTAINMENT DISPLAY SIG LVDS SIG RADIO RED/WHT WIRE UNDERHOOD FUSE BLOCK WHT WIRE WHT/BLK WIRE

AUXILIARY COOLANT PUMP (NEAR OIL FILTER) BATTERY FUSE BLOCK BLK WIRE BRN/YEL WIRE COOLING FAN HIGH SPEED RELAY COOLING FAN LOW SPEED RELAY COOLING FAN MEDIUM SPEED RELAY COOLING FAN MOTOR (BEHIND RADIATOR) ENGINE CONTROLS IGNITION RELAY GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES RED/VIO WIRE RED/WHT WIRE UNDERHOOD FUSE BLOCK WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
