A/c circuit, passenger van for Chevrolet RV Cutaway G3500 (1997-2013)

A/C COMPRESSOR CLUTCH COIL A/C COMPRESSOR CLUTCH RELAY (IN UNDERHOOD FUSE/RELAY CENTER) A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF A/C COMPRESSOR) A/C COMPRESSOR LOW PRESSURE CUTOFF SWITCH (DIESEL) (IN REFRIGERANT LINE) A/C COMPRESSOR LOW PRESSURE CUTOFF SWITCH (GASOLINE) (IN REFRIGERANT LINE) AUXILIARY BLOWER MOTOR AUXILIARY BLOWER MOTOR RESISTOR (LEFT REAR OF CABIN, BEHIND REAR WHEELHOUSE) BLK WIRE BLOWER FUSE BLOWER MOTOR BLOWER MOTOR RESISTOR/RELAY (AT HVAC CONTROL PANEL) BRN WIRE COMPT AT LEFT FENDER) POWERTRAIN CONTROL MODULE (BEHIND (DIESEL) CENTER OF DASH) CONVENIENCE CENTER DIODE (IN UNDERHOOD FUSE/RELAY CENTER) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT AUXILIARY HVAC CONTROL MODULE GASOLINE GASOLINE DIESEL GRY WIRE HEATER AND A/C CONTROL LOGIC MODULE (FRONT INTERIOR ROOF PANEL) HEATER AND A/C CONTROLLER HOT AT ALL TIMES HOT AT ALL TIMES HOT IN RUN OR START HOT IN RUN HTR A/C FUSE 12 I/P FUSE BLOCK LT BLU WIRE LT GRN WIRE OFF LO MED HI OFF MAX A/C BI-LEV ORG/ WIRE PNK WIRE PPL REAR AUXILIARY HVAC CONTROL MODULE REAR AUXILIARY MODE VALVE AND SEAL ASSY (LEFT REAR INTERIOR) REAR AUXILIARY TEMPERATURE VALVE ASSY (LEFT REAR INTERIOR) RED WIRE RR BLOWER FUSE RR CTRL OFF LO MED HI RR HVAC FUSE 24 TAN WIRE TEMP UNDER HOOD FUSE-RELAY CENTER UNDER- HOOD FUSE/ RELAY CENTER A/C FUSE IGN E FUSE VEHICLE CONTROL MODULE (IN ENGINE VENT HEAT BLEND DEF VENT HEAT BLEND DEF OFF MAX A/C BI-LEV VENT MODE WHT WIRE YEL WIRE
