Chevrolet RV Cutaway G3500 (1997-2013) selector sw Wiring diagram
This page shows the only wiring diagram for the component.selector sw, which is found in the car Chevrolet RV Cutaway G3500 (1997-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector sw (1 of 1)
AMB AIR TEMP SENS SIG LOW REF
AMB LGHT SENSOR REAR LGHT SENSOR
AMBIENT AIR TEMPERATURE SENSOR (BEHIND FRONT GRILLE, ON RADIATOR SUPPORT)
BACKUP LAMP PWR
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
ELECTRO- CHROMIC
EXTERIOR LIGHTS SYSTEM (W/ PASSENGER/ CARGO)
GRN WIRE
GROUND
HOT IN RUN AND START
IGN 1 VLT
INSIDE REARVIEW MIRROR
ISRVM FUSE 26
LOGIC BACKUP LAMP PWR
LT GRN WIRE
PNK WIRE
SELECTOR SW
TAN WIRE
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Automatic day/night mirror circuit -> SELECTOR SW
