Chevrolet RV Cutaway G3500 (1997-2013) right rear access panel relay Wiring diagram
This page shows the only wiring diagram for the component.right rear access panel relay, which is found in the car Chevrolet RV Cutaway G3500 (1997-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear access panel relay (1 of 1)
7 CM FROM BREAKOUT FOR REAR FUSE BLOCK)
AIR BAG FUSE 28
BLK WIRE
BODY CONTROL MODULE (BCM)
BRK SW IPC FUSE 10 FUSE 13
BRN WIRE
CONNECTOR
CONTENT THEFT DETERRENT MODULE (TDM)
DK BLU WIRE
DOME FLUORESCENT WORK LAMPS FUSE 2
FROM MEGA FUSE (DIAGRAM 2 OF 5)
FROM PASSENGER COMPARTMENT FUSE BLOCK (DIAGRAM 4 OF 5)
FSCM IGN FUSE 6
FUEL PUMP CONTROL MODULE (5.3L)
HARNESS, 15 CM FROM REAR FUSE BLOCK)
HARNESS, 8 CM FROM REAR FUSE BLOCK)
IGN
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT CLUSTER
KEY-IN SWITCH
LEFT FRONT ACCESS PANEL RELAY
LEFT REAR ACCESS PANEL RELAY
OFF
ORG/ WIRE
PANEL ACTUATOR FUSE 3
PNK WIRE
REAR FUSE BLOCK (ON LEFT "B" PILLAR)
RED WIRE
RED/ WHT WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT REAR ACCESS PANEL RELAY
RUN WIRE
RUN/CRNK RELAY 15
STEERING WHEEL SPEED/ ANGLE SENSOR
STOP LAMP SWITCH
STR/WHL SNSR FUSE 29 (W/ ACTIVE BRAKE CONTROL)
TO TRANS FUSE 17 (DIAGRAM 5 OF 5)
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
W/ CARGO LAMP
W/O RV UPFITTER, MANUAL W/ MANUAL SUPPRESSION SUPPRESSION
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> RIGHT REAR ACCESS PANEL RELAY
