Chevrolet RV Cutaway G3500 (1997-2013) left headlamp Wiring diagrams
This page contains all the electrical diagrams for the component. left headlamp, in which he is found in the car Chevrolet RV Cutaway G3500 (1997-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left headlamp (1 of 7)
A/C FUSE 32
A/C RELAY 54
AUXILIARY 2 FUSE 33 REAR DOOR LKS FUSE 5
AUXILIARY RELAY 24
CAN VENT FUSE 34
CARGO UNLK RELAY 27
COMPOSITE+
DK GRN/WHT WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY 30
DRV LKS FUSE 7 HTD MIR/DEFOG FUSE 12
DRV UNLK RELAY 28
EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT SOLENOID
FROM UNDERHOOD FUSE BLOCK (HDLP HI BEAM RELAY) (DIAGRAM 2 OF 6)
FROM UNDERHOOD FUSE BLOCK (MEGA FUSE 65) (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (PWR SEAT CIRCUIT BREAKER 60) (DIAGRAM 1 OF 6)
FUEL PUMP FUSE 12
FUEL PUMP RELAY 57
HDLP HI BEAM RELAY 56
HDLP LO BEAM RELAY 58
HORN FUSE 15
HORN RELAY 59
IGN A FUSE 49
IGN B FUSE 52
LEFT HEADLAMP
LEFT HI BEAM FUSE 44
LEFT HIGH BEAM HEADLAMP
LEFT LO BEAM FUSE 43
LEFT LOW BEAM HEADLAMP
LT GRN/BLK WIRE
PASS UNLK RELAY 31
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HI BEAM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LO BEAM FUSE 42
RIGHT LOW BEAM HEADLAMP
RR DEFOG RELAY 25
SEALED
SPARE FUSE 33
SPARE RELAY 55
SPARE RELAY 62
STARTER RELAY 61
TAN/WHT WIRE
TO BODY FUSE BLOCK (PARK LP RELAY) (DIAGRAM 3 OF 6)
TO IGNITION SWITCH (DIAGRAM 3 OF 6)
TO UNDERHOOD FUSE BLOCK (IGN A FUSE 49) (DIAGRAM 2 OF 6)
WSW FUSE 41
WSW RELAY 53
YEL WIRE
Go to component -> 4.8l vin v, power distribution circuit (2 of 6) -> LEFT HEADLAMP
Wiring diagram left headlamp (2 of 7)
A/C FUSE 32
A/C RELAY 54
AUXILIARY 2 FUSE 33 REAR DOOR LKS FUSE 5
AUXILIARY RELAY 24
CAN VENT FUSE 34
CARGO UNLK RELAY 27
COMPOSITE+
DK GRN/WHT WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY 30
DRV LKS FUSE 7 HTD MIR/DEFOG FUSE 12
DRV UNLK RELAY 28
EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT SOLENOID
FROM UNDERHOOD FUSE BLOCK (HDLP HI BEAM RELAY) (DIAGRAM 2 OF 6)
FROM UNDERHOOD FUSE BLOCK (MEGA FUSE 65) (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (PWR SEAT CIRCUIT BREAKER 60) (DIAGRAM 1 OF 6)
FUEL PUMP FUSE 12
FUEL PUMP RELAY 57
HDLP HI BEAM RELAY 56
HDLP LO BEAM RELAY 58
HORN FUSE 15
HORN RELAY 59
IGN A FUSE 49
IGN B FUSE 52
LEFT HEADLAMP
LEFT HI BEAM FUSE 44
LEFT HIGH BEAM HEADLAMP
LEFT LO BEAM FUSE 43
LEFT LOW BEAM HEADLAMP
LT GRN/BLK WIRE
PASS UNLK RELAY 31
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HI BEAM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LO BEAM FUSE 42
RIGHT LOW BEAM HEADLAMP
RR DEFOG RELAY 25
SEALED
SPARE FUSE 33
SPARE RELAY 55
SPARE RELAY 62
STARTER RELAY 61
TAN/WHT WIRE
TO BODY FUSE BLOCK (PARK LP RELAY) (DIAGRAM 3 OF 6)
TO IGNITION SWITCH (DIAGRAM 3 OF 6)
TO UNDERHOOD FUSE BLOCK (IGN A FUSE 49) (DIAGRAM 2 OF 6)
WSW FUSE 41
WSW RELAY 53
YEL WIRE
Go to component -> 6.0l vin u, power distribution circuit (2 of 6) -> LEFT HEADLAMP
Wiring diagram left headlamp (3 of 7)
A/C FUSE 32
A/C RELAY 54
AUXILIARY 2 FUSE 33 REAR DOOR LKS FUSE 5
AUXILIARY RELAY 24
CARGO UNLK RELAY 27
COMPOSITE+
DK GRN/WHT WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY 30
DRV LKS FUSE 7
DRV UNLK RELAY 28
E.C.M. FUSE 33
ECM ACT FUSE 63
ECM RELAY 62
ENGINE CONTROL MODULE (ECM)
FROM UNDERHOOD FUSE BLOCK (HDLP HI BEAM RELAY) (DIAGRAM 2 OF 6)
FROM UNDERHOOD FUSE BLOCK (MEGA FUSE 65) (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (PWR SEAT CIRCUIT BREAKER 60) (DIAGRAM 1 OF 6)
FUEL PUMP FUSE 12
FUEL PUMP RELAY 57
HDLP HI BEAM RELAY 56
HDLP LO BEAM RELAY 58
HORN FUSE 15
HORN RELAY 59
HTD MIR/DEFOG FUSE 12
IGN A FUSE 49
IGN B FUSE 52
LEFT HEADLAMP
LEFT HI BEAM FUSE 44
LEFT HIGH BEAM HEADLAMP
LEFT LO BEAM FUSE 43
LEFT LOW BEAM HEADLAMP
LT GRN/BLK WIRE
PASS UNLK RELAY 31
REAR FOG LAMPS FUSE 34
REAR FOG LAMPS RELAY 55
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HI BEAM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LO BEAM FUSE 42
RIGHT LOW BEAM HEADLAMP
RR DEFOG RELAY 25
SEALED
STARTER RELAY 61
TAN/WHT WIRE
TO BODY FUSE BLOCK (PARK LP RELAY) (DIAGRAM 3 OF 6)
TO IGNITION SWITCH (DIAGRAM 3 OF 6)
TO UNDERHOOD FUSE BLOCK (IGN A FUSE 49) (DIAGRAM 2 OF 6)
WSW FUSE 41
WSW RELAY 53
YEL WIRE
Go to component -> 6.6l vin 2, power distribution circuit (2 of 6) -> LEFT HEADLAMP
Wiring diagram left headlamp (4 of 7)
A/C FUSE 32
A/C RELAY 54
AUXILIARY 2 FUSE 33 REAR DOOR LKS FUSE 5
AUXILIARY RELAY 24
CARGO UNLK RELAY 27
COMPOSITE+
DK GRN/WHT WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY 30
DRV LKS FUSE 7
DRV UNLK RELAY 28
E.C.M. FUSE 33
ECM ACT FUSE 63
ECM RELAY 62
ENGINE CONTROL MODULE (ECM)
FROM UNDERHOOD FUSE BLOCK (HDLP HI BEAM RELAY) (DIAGRAM 2 OF 6)
FROM UNDERHOOD FUSE BLOCK (MEGA FUSE 65) (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (PWR SEAT CIRCUIT BREAKER 60) (DIAGRAM 1 OF 6)
FUEL PUMP FUSE 12
FUEL PUMP RELAY 57
HDLP HI BEAM RELAY 56
HDLP LO BEAM RELAY 58
HORN FUSE 15
HORN RELAY 59
HTD MIR/DEFOG FUSE 12
IGN A FUSE 49
IGN B FUSE 52
LEFT HEADLAMP
LEFT HI BEAM FUSE 44
LEFT HIGH BEAM HEADLAMP
LEFT LO BEAM FUSE 43
LEFT LOW BEAM HEADLAMP
LT GRN/BLK WIRE
PASS UNLK RELAY 31
REAR FOG LAMPS FUSE 34
REAR FOG LAMPS RELAY 55
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HI BEAM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LO BEAM FUSE 42
RIGHT LOW BEAM HEADLAMP
RR DEFOG RELAY 25
SEALED
STARTER RELAY 61
TAN/WHT WIRE
TO BODY FUSE BLOCK (PARK LP RELAY) (DIAGRAM 3 OF 6)
TO IGNITION SWITCH (DIAGRAM 3 OF 6)
TO UNDERHOOD FUSE BLOCK (IGN A FUSE 49) (DIAGRAM 2 OF 6)
WSW FUSE 41
WSW RELAY 53
YEL WIRE
Go to component -> 6.6l vin 6, power distribution circuit (2 of 6) -> LEFT HEADLAMP
Wiring diagram left headlamp (5 of 7)
33 33 BRAKE IND CTRL BRAKE PSI IN DRL RELAY CTRL
39 10 10 PNK IGN (RUN/ST) LAMP FEED WIRE
BLK WIRE
COMPOSITE HEADLAMPS SEALED BEAM HEADLAMPS
DAYTIME RUNNING LAMP DIODE MODULE (UNDER LEFT SIDE OF DASH)
DK GRN WIRE
DRL FUSE 15
DRL INDICATOR
ELECTRONIC BRAKE CONTROL MODULE
GAUGES FUSE 4
GRN WIRE
GROUND
GRY WIRE
HEAD
HEADLAMP DIMMER SWITCH
HEADLAMP LEVELING SWITCH
HEADLAMP SWITCH
HI LO
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (ON LEFT LOWER KICK PANEL)
IGNITION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT HEADLAMP
LEFT HEADLAMP LEVELING ACTUATOR
LEFT HIGH BEAM HEADLAMP LAMP
LEFT LOW BEAM HEADLAMP LAMP
LIGHTING FUSE
LOCK OFF
LOGIC PNK WIRE
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT LT
LT/BLU WIRE
NCA WIRE
OFF
ORG/ WIRE
PARK
PARK BRAKE IN IGN KEY STATUS
PARK BRAKE WARNING SWITCH (NEAR LEFT KICK PANEL, ON PARK BRAKE LEVER)
PNK WIRE
PPL
PPL LT (I/P HARN, 8 CM TOWARD PARK BRAKE WARNING SWITCH BREAKOUT)
RED WIRE
RIGHT HEADLAMP
RIGHT HEADLAMP LEVELING ACTUATOR
RIGHT HIGH BEAM HEADLAMP LAMP
RIGHT LOW BEAM HEADLAMP LAMP
RUN WIRE
SEALED BEAM HEADLAMPS COMPOSITE HEADLAMPS
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Headlight circuit -> LEFT HEADLAMP
Wiring diagram left headlamp (6 of 7)
BLK WIRE
BRAKE IND CTRL BRAKE PSI IN DRL RELAY CTRL
BULB TEST LOCK OFF
DAYTIME RUNNING LAMPS MODULE (UNDER LEFT SIDE OF I/P, TAPED TO I/P HARNESS)
DAYTIME RUNNING LAMPS RELAY (UNDER LEFT SIDE OF I/P, ON CONVENIENCE CENTER)
DRL DIODE MODULE
DRL FUSE 15
DRL INDICATOR
FROM 36-PIN LEFT BULKHEAD CONN) BREAKOUT) LT
GAUGES FUSE 4
GRN WIRE
GROUND
HEAD
HEADLAMP DIMMER SWITCH
HEADLAMP SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (LEFT KICK PANEL)
IGNITION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FORWARD LAMP BREAKOUT TOWARD RIGHT)
LEFT FORWARD LAMP BREAKOUT)
LEFT HEADLAMP
LIGHTING MAXI FUSE
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT PPL
OFF PARK
ORG/ WIRE
PARK BRAKE IN IGN KEY STATUS
PARK BRAKE WARNING SWITCH (ON PARK BRAKE)
PNK IGN (RUN/ST) LAMP FEED WIRE
PNK WIRE
PPL
RED WIRE
RIGHT HEADLAMP
RUN WIRE
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE-RELAY CENTER (ENGINE COMPT, LEFT FENDER)
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, with sealed beam headlamps -> LEFT HEADLAMP
Wiring diagram left headlamp (7 of 7)
A/C FUSE 32
A/C RELAY
AUXILIARY 2 FUSE 33 CARGO LKS FUSE 5
AUXILIARY RELAY
CAN VENT FUSE 34
CARGO UNLK RELAY
COMPOSITE+
DK GRN/WHT WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY
DRV LKS FUSE 7 HTD MIR/DEFOG FUSE 12
DRV UNLK RELAY
EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT SOLENOID
FROM UNDERHOOD FUSE BLOCK (HDLP HIBM RELAY) (DIAGRAM 2 OF 6)
FROM UNDERHOOD FUSE BLOCK (MEGA FUSE 65) (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (PWR SEAT CIRCUIT BREAKER 60) (DIAGRAM 1 OF 6)
FUEL PUMP FUSE 12
FUEL PUMP RELAY
HDLP HIBM RELAY
HDLP LOBM RELAY
HORN FUSE 15
HORN RELAY
IGN A FUSE 49
IGN B FUSE 52
LEFT HEADLAMP
LEFT HIBM FUSE 44
LEFT HIGH BEAM HEADLAMP
LEFT LOBM FUSE 43
LEFT LOW BEAM HEADLAMP
LT GRN/BLK WIRE
PASS UNLK RELAY
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HIBM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LOBM FUSE 42
RIGHT LOW BEAM HEADLAMP
RR DEFOG RELAY
SEALED
SPARE FUSE 33
SPARE RELAY 55
SPARE RELAY 62
STARTER RELAY
TAN/WHT WIRE
TO BODY FUSE BLOCK (PARK LP RELAY) (DIAGRAM 3 OF 6)
TO IGNITION SWITCH (DIAGRAM 3 OF 6)
TO UNDERHOOD FUSE BLOCK (IGN A FUSE 49) (DIAGRAM 2 OF 6)
WPR FUSE 41
WPR RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> LEFT HEADLAMP
