Chevrolet RV Cutaway G3500 (1997-2013) ground int lts in lock sig unlock sig ppl Wiring diagram

195 156 LOCK OUT DOME LAMPS BATT (B+) BATT (B+) RR DOOR UNLK PASS DRS UNLK IGNITION DOME LMP OFF PROGRAM SIG BLK WIRE BLK/WHT WIRE CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DOOR LOCK CONTROL MODULE (ON LEFT KICK PANEL) DRIVER DOOR LOCK ACTUATOR DRIVER DR UNLK UNLOCK IN DRIVER POWER DOOR LOCK SWITCH FRONT PASSENGER DOOR LOCK ACTUATOR FRONT PASSENGER POWER DOOR LOCK SWITCH GAUGES FUSE 4 GROUND GROUND INT LTS IN LOCK SIG UNLOCK SIG PPL GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (ON LEFT LOWER KICK PANEL) PWR ACCY FUSE A LOCK LT BLU WIRE ORG/ WIRE PNK WIRE POWER DOOR LOCK RELAY (BEHIND CENTER OF DASH) REAR CARGO DOOR LOCK SWITCH REAR DOOR LOCK ACTUATOR REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND CENTER OF DASH) SIDE DOOR CONTACTOR (RIGHT "B" PILLAR) SIDE DOOR JAMB SWITCH SIDE DOOR LOCK ACTUATOR SIDE DOOR SW BATTERY (B+) TAN WIRE UNLOCK WHT WIRE WHT/BLK WIRE
