Chevrolet RV Cutaway G3500 (1997-2013) dome lamp override switch Wiring diagram
This page shows the only wiring diagram for the component.dome lamp override switch, which is found in the car Chevrolet RV Cutaway G3500 (1997-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dome lamp override switch (1 of 1)
ASH TRAY LAMP
BATTERY IGNITION DR JAMB SW GROUND DOME LAMP
BLK WIRE
BRIGHT ADJUST
BRN WIRE
CENTER DOME, READING LAMP
CTSY FUSE 3
DK GRN WIRE
DOME LAMP
DOME LAMP OVERRIDE SWITCH
DOME SWITCH
FRONT DOME, READING LAMP
GAUGES FUSE 4
GRY WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN, START
I/P COMPART- MENT LAMP
I/P FUSE BLOCK
IGNITION DR JAMB SW BATTERY GROUND
ILLUMINATED ENTRY MODULE (ON RIGHT LOWER KICK PANEL)
JAMB SWITCH W/ RKE
LAMP
LEFT FRONT DOOR JAMB SWITCH RIGHT FRONT DOOR JAMB SWITCH
LEFT FRONT POWER DOOR LOCK SWITCH LEFT FRONT POWER WINDOW SWITCH
LEFT STEPWELL LAMP
LEFT SUNSHADE MIRROR LAMP
NCA WIRE
NON BASE ONLY
ORG/ WIRE
PARADE MODE SWITCH
PARK LPS FUSE 9
PARK SWITCH
PNK 157 540 150 156 WIRE
PNK W/ RKE WIRE
PNK W/O RKE WIRE
PNK WIRE
POWER DOOR LOCK CONTROL MODULE (ON LEFT KICK PANEL)
PPL
PWR ACCY FUSE A
READING LAMPS
REAR DOME/ READING LAMP
REAR DOOR)
REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND CENTER OF DASH)
RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT POWER DOOR LOCK SWITCH
RIGHT SUNSHADE MIRROR LAMP
SIDE DOOR JAMB SWITCH
SIDE STEPWELL LAMP RIGHT STEPWELL LAMP
TO I/P FUSE BLOCK (DIAGRAM 2 OF 2)
W/ POWER DOOR LOCKS W/O POWER DOOR LOCKS
W/ RKE
W/ RKE W/O RKE
W/O RKE
W/O RKE PPL
WHT WIRE
Go to component -> Interior light circuit (1 of 2) -> DOME LAMP OVERRIDE SWITCH
