Chevrolet RV Cutaway G3500 (1997-2013) 358 238 indicator ctrl seat belt sw sensor input ignition 8 9 10 11 12 349 1139 Wiring diagram
This page shows the only wiring diagram for the component.358 238 indicator ctrl seat belt sw sensor input ignition 8 9 10 11 12 349 1139, which is found in the car Chevrolet RV Cutaway G3500 (1997-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 358 238 indicator ctrl seat belt sw sensor input ignition 8 9 10 11 12 349 1139 (1 of 1)
1000 OHMS
2 OHMS
358 238 INDICATOR CTRL SEAT BELT SW SENSOR INPUT IGNITION 8 9 10 11 12 349 1139
5 6 SERIAL DATA GROUND
AIR BAG INDICATOR
AIR BAGS FUSE 10
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DK GRN WIRE
DK GRN/WHT WIRE
GAUGES FUSE 4
GRY WIRE
HOT IN RUN, START
I/P FUSE BLOCK (ON LOWER LEFT KICK PANEL)
INFLATABLE RESTRAINT DIAGNOSTIC RESISTOR
INFLATABLE RESTRAINT FRONT END DISCRIMINATING SENSOR (ON FRONT OF VEHICLE)
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER LEFT FRONT SEAT)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL SHORTING BAR
INSTRUMENT CLUSTER
MULTI-FUNCTION ALARM MODULE (UNDER LEFT SIDE OF DASH)
NCA WIRE
PNK WIRE
SEAT BELT SWITCH (OPEN WHEN BUCKLED) (AT DRIVER'S STATIONARY BELT CONNECTOR)
SHORTING BAR
TAN WIRE
W/ PASS SIR
W/O PASS SIR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit -> 358 238 INDICATOR CTRL SEAT BELT SW SENSOR INPUT IGNITION 8 9 10 11 12 349 1139
