Chevrolet RV Cutaway G3500 (1997-2013) 1 2 3 4 battery b+ serial data pnk Wiring diagram

1 2 3 4 BATTERY B+ SERIAL DATA PNK WIRE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH) BODY FUSE BLOCK (UNDER LEFT FRONT SEAT) CARGO DOOR LATCH ASSEMBLY CARGO UNLK FUSE 5 CARGO UNLK RELAY 27 DK BLU WIRE DOOR LKS FUSE 15 DOOR LKS RELAY 30 DOOR LOCK CTRL UNLOCK CTRL DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR LOCK SWITCH DRV LKS FUSE 7 DRV UNLK RELAY 28 FRONT PASSENGER DOOR LATCH ASSEMBLY FRONT PASSENGER DOOR LOCK SWITCH GROUND GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER LEFT REAR SIDE DOOR LOCK ACTUATOR LEFT SIDE DOOR CONTACT PLATE (LEFT "B" PILLAR) LT BLU WIRE LT GRN WIRE PASS UNLK RELAY 31 REAR CARGO DOOR LOCK SWITCH RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND CENTER OF DASH) RIGHT REAR SIDE DOOR LOCK ACTUATOR RIGHT SIDE DOOR CONTACT PLATE (RIGHT "B" PILLAR) SERIAL DATA SERIAL DATA UNLOCK RLY CTRL SW UNLOCK CTRL SW LOCK CTRL RELEASE RLY CTRL SPLICE SPLICE PACK TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) RFA FUSE 20 WHT WIRE
