Chevrolet Prizm I (1997-2002) w/ button depressed) Wiring diagrams
This page contains all the electrical diagrams for the component. w/ button depressed), in which he is found in the car Chevrolet Prizm I (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ button depressed) (1 of 2)
16 1 15 11 10 IGNITION BATTERY MIL CTRL SERIAL DATA CRUSIE IDLE
2 14 18 23 8 17 REF VOLTAGE ECT SENS SENSOR GND TP SENS GROUND GROUND
20 19 8 21 31 SHIFT SOL 2 TCC SOL SHIFT SOL 1 GROUND GROUND
AUTOMATIC TRANSAXLE (FOUR-SPEED)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CRUISE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR (OBD) (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (UNDERHOOD) (ON LEFT STRUT TOWER)
EFI FUSE
EFI RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (RIGHT REAR OF ENGINE)
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT)
GAUGE FUSE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN FUSE
INSTRUMENT CLUSTER
JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL)
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (BEHIND
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MALFUNCTION INDICATOR
MULTI-FUNCTION ALARM MODULE (LEFT SIDE OF DASH)
NCA WIRE
O/D OFF INDICATOR
OF DASH)
OVERDRIVE SWITCH (OPEN
PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE, BELOW BATTERY)
POWERTRAIN CONTROL MODULE (BEHIND FRONT OF CENTER CONSOLE)
PPL
PPL/WHT WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SHIFT SOLENOID 1
SHIFT SOLENOID 2 TORQUE CONVERTER CLUTCH SOLENOID
SPEEDO- METER
STARTING/ CHARGING SYSTEM
STOP FUSE
STOP LAMP SWITCH (TOP OF BRAKE PEDAL BRACKET)
THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY)
VEHICLE SPEED SENSOR (ON TOP OF TRANSAXLE)
W/ BUTTON DEPRESSED)
W/ CRUISE CONTROL
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> 1.8l vin 8, a/t circuit, with 4 speed a/t -> W/ BUTTON DEPRESSED)
Wiring diagram w/ button depressed) (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CAMSHAFT POSITION ACTUATOR SOLENOID VALVE (TOP LEFT FRONT OF ENGINE)
CRUISE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
EVAP CANISTER PURGE SOLENOID VALVE (LEFT SIDE OF ENGINE COMPT) SHIFT SOLENOID 1
GAUGE FUSE
HOT IN ON OR START
INSTRUMENT CLUSTER
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (BEHIND
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BLU WIRE
MALFUNCTION INDICATOR LAMP
MULTI-FUNCTION ALARM MODULE (LEFT SIDE OF DASH)
O/D OFF INDICATOR LAMP
OF DASH)
OVERDRIVE SWITCH (OPEN
POWER STEERING PRESSURE SWITCH (TOP OF POWER STEERING PUMP)
PPL
PPL/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
TACH INPUT
TORQUE CONVERTER CLUTCH SOLENOID SHIFT SOLENOID 2
VEHICLE SPEED
W/ BUTTON DEPRESSED)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8s, with 4 speed a/t (2 of 3) -> W/ BUTTON DEPRESSED)
