Chevrolet Prizm I (1997-2002) shift lock solenoid control Wiring diagram
This page shows the only wiring diagram for the component.shift lock solenoid control, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock solenoid control (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE SIGNAL
CIG FUSE
ECU-IG FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
HOT IN ON, START
IGNITION
IGNITION KEY LOCK SOLENOID (MOUNTED TO IGNITION SWITCH HOUSING)
JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL)
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH, BEHIND STORAGE BOX COVER)
JUNCTION BLOCK 3 (BEHIND CENTER OF DASH)
KEY LOCK SOLENOID CONTROL
MULTI-FUNCTION ALARM MODULE
R,N,D,2,L SIGNAL SIGNAL GND GND
RED WIRE
SHIFT LOCK SOLENOID CONTROL
STOP FUSE
STOPLAMP SWITCH (ON BRAKE SUPPORT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> SHIFT LOCK SOLENOID CONTROL
