Chevrolet Prizm I (1997-2002) shift lock control module Wiring diagrams
This page contains all the electrical diagrams for the component. shift lock control module, in which he is found in the car Chevrolet Prizm I (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shift lock control module (1 of 2)
A/C SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CENTER HIGH MOUNT STOPLAMP
CIGAR LIGHTER
DIAGNOSTIC MODULE (SDM)
FROM
FUEL SENDER ASSEMBLY
I/P LAMP DIMMER
IGNITION KEY ALARM SWITCH IGNITION KEY LOCK SOLENOID
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 3 (CENTER OF DASH)
LEFT "C" PILLAR)
NCA WIRE
OUTSIDE REAR VIEW MIRROR SWITCH
OVERDRIVE SWITCH
RADIO
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP LEFT REAR COMBINATION LAMP
SEAT BELT SWITCH
SHIFT LOCK CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 3) -> SHIFT LOCK CONTROL MODULE
Wiring diagram shift lock control module (2 of 2)
BLK WIRE
BLU WIRE
CIG FUSE
CIGAR LIGHTER
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE
DIAGNOSTIC MODULE (SDM)
DOME LAMP SUNROOF SWITCH ASSEMBLY
EFI RELAY
FROM DOME FUSE (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH PIN 3 (DIAGRAM 2 OF 3)
FROM IGNITION SWITCH PIN 6 (DIAGRAM 2 OF 3)
FUEL INJECTORS
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPARTMENT)
GRY WIRE
IGN FUSE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INFLATABLE RESTRAINT SENSING
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 1 (LEFT KICK PANEL)
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (CENTER OF DASH)
MULTI-FUNCTION ALARM MODULE
NOISE FILTER
ORG/ WIRE
OUTSIDE REAR VIEW MIRROR SWITCH RADIO MULTI-FUNCTION ALARM MODULE
RADIO
REAR COMPARTMENT LAMP
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
SHIFT LOCK CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> SHIFT LOCK CONTROL MODULE
