Chevrolet Prizm I (1997-2002) left front solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.left front solenoid valve, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front solenoid valve (1 of 1)
ABS FUSE
ABS IND DRIVER MODULE SOLID STATE
ABS PUMP MOTOR
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV) (LEFT REAR OF ENGINE COMPT)
BRN WIRE
DATA LINK CONNECTOR (DLC) OBD II (BEHIND LEFT SIDE OF DASH)
ECU-IG FUSE
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GROUND BATTERY GROUND BATTERY
HOT AT ALL TIMES
HOT IN ON, START
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL)
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (BEHIND CENTER OF DASH)
LEFT FRONT SOLENOID VALVE
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR SOLENOID VALVE
LEFT REAR WHEEL SPEED SENSOR
MULTI-FUNCTION ALARM MODULE
PNK LR SPD SENS WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT SOLENOID VALVE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR SOLENOID VALVE
RIGHT REAR WHEEL SPEED SENSOR
SERIAL DATA BRAKE SW CHECK CONN
STOP FUSE
STOPLAMP SWITCH (ON TOP OF BRAKE PEDAL BRACKET)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> LEFT FRONT SOLENOID VALVE
