Chevrolet Prizm I (1997-2002) i/p lamp power dimmer solid state bulbs Wiring diagram
This page shows the only wiring diagram for the component.i/p lamp power dimmer solid state bulbs, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i/p lamp power dimmer solid state bulbs (1 of 1)
A/C SWITCH
ASHTRAY ILLUMINATION LAMP
AUTOMACTIC TRANSAXLE CONTROL LEVER ILLUMINATION LAMP
BLK WIRE
BLOWER SPEED SELECTOR SWITCH
BLU WIRE
BLU/YEL WIRE
CIGAR LIGHTER ILLUMINATION LAMP
DIM CTRL
DOME FUSE
DOME LAMP
DOME LAMP CONTROL
DOOR OPEN SIG
FROM J/B 1 (DIAGRAM 1 OF 1)
FROM SUNROOF BRANCH BREAKOUT)
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT, LEFT OF AIR CLEANER)
GRN WIRE
GROUND
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN PARK OR HEAD
I/P LAMP POWER DIMMER SOLID STATE BULBS
INSTRUMENT CLUSTER ASSEMBLY
J/B 3 (BEHIND CENTER OF DASH)
JUNCTION BLOCK 1 (LEFT KICK PANEL)
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (CENTER OF DASH)
LEFT FRONT DOOR JAMB SWITCH
LEFT FRT DOOR OPEN SIG
LEFT REAR DOOR JAMB SWITCH RIGHT REAR DOOR JAMB SWITCH
LIGHTS ON SIGNAL
MAP LAMP
MAP LAMP SWITCH
NCA WIRE
OFF
ON OFF DOOR
POWERTRAIN CONTROL MODULE (PCM) (BEHIND FRONT OF CENTER CONSOLE)
RADIO ILLUM INPUT
REAR COMPARTMENT LAMP
REAR COMPARTMENT LAMP SWITCH
REAR DEFOGGER SWITCH
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR JAMB SWITCH
RIGHT FRT DOOR OPEN SIG
SUN ROOF SWITCH ASSEMBLY
TAIL FUSE
TO HAZARD SWITCH (DIAGRAM 1 OF 1)
W/O RKE W/ RKE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Interior light circuit -> I/P LAMP POWER DIMMER SOLID STATE BULBS
