Chevrolet Prizm I (1997-2002) ignition key alarm switch ignition key lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.ignition key alarm switch ignition key lock solenoid, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition key alarm switch ignition key lock solenoid (1 of 1)
A/C SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CENTER HIGH MOUNT STOPLAMP
CIGAR LIGHTER
DIAGNOSTIC MODULE (SDM)
FROM
FUEL SENDER ASSEMBLY
I/P LAMP DIMMER
IGNITION KEY ALARM SWITCH IGNITION KEY LOCK SOLENOID
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 3 (CENTER OF DASH)
LEFT "C" PILLAR)
NCA WIRE
OUTSIDE REAR VIEW MIRROR SWITCH
OVERDRIVE SWITCH
RADIO
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP LEFT REAR COMBINATION LAMP
SEAT BELT SWITCH
SHIFT LOCK CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 3) -> IGNITION KEY ALARM SWITCH IGNITION KEY LOCK SOLENOID
