Chevrolet Prizm I (1997-2002) hot in on, start gauge fuse Wiring diagram
This page shows the only wiring diagram for the component.hot in on, start gauge fuse, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on, start gauge fuse (1 of 1)
A/T
BACK UP LAMP
BACK-UP LAMP SWITCH (TOP OF TRANSAXLE)
HOT IN ON, START GAUGE FUSE
JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL)
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (BEHIND CENTER OF DASH)
LEFT REAR COMBINATION LAMP
M/T
MULTI- FUNCTION ALARM MODULE (BEHIND LEFT SIDE OF DASH)
PARK/ NEUTRAL POSITION (PNP) SWITCH (ON TRANSAXLE, BELOW BATTERY)
POS SIG
POWERTRAIN CONTROL MODULE (PCM) (4-SPD ONLY) (BEHIND FRONT OF CENTER CONSOLE)
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR COMBINATION LAMP
WHT/BLK WIRE
