Chevrolet Prizm I (1997-2002) ground door sw sig ignition Wiring diagram
This page shows the only wiring diagram for the component.ground door sw sig ignition, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground door sw sig ignition (1 of 1)
16 17 TAIL RLY CTRL PK LT SIG
ALT FUSE
BELT IND CTRL BATTERY KEY-IN SIG BELT SW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
DOOR IND CTRL
DOOR OPEN IND
DRL CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
EXT LTS OUT
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT) DOME FUSE
GAUGE FUSE
GRN WIRE
GROUND DOOR SW SIG IGNITION
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN ON OR START
IGNITION
IGNITION 2 3 4 5 6 7 8 9 10 11
IGNITION KEY ALARM SWITCH
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 1
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH) CIG FUSE
JUNCTION BLOCK 3
JUNCTION BLOCK 3 (BEHIND CENTER OF DASH)
LEFT "C" PILLAR)
LEFT FRONT DOOR JAMB SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
LTS ON INPUT
MULTI- FUNCTION ALARM MODULE (BEHIND LEFT SIDE OF DASH)
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SEAT BELT IND
SEAT BELT SWITCH (SEAT BELT RET)
TAIL FUSE
TAIL RELAY
TURN SIGNAL/ HEADLAMP COMBINATION SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Warning system circuits -> GROUND DOOR SW SIG IGNITION
