Chevrolet Prizm I (1997-2002) engine main relay Wiring diagrams
This page contains all the electrical diagrams for the component. engine main relay, in which he is found in the car Chevrolet Prizm I (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram engine main relay (1 of 2)
A/C COMPRESSOR CLUTCH
A/C FAN 2 RELAY HTR RELAY
A/C FAN 3 RELAY
BATTERY
BLK WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PRESSURE MODULATOR VALVE (BPMPV)
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
CAMSHAFT POSITION (CMP) SENSOR SHIELD
DATA LINK CONNECTOR (DLC)
DATA LINK CONNECTOR- ON-BOARD DIAGNOTICS II (DLC-OBD II)
DATA LINK CONNECTOR- ON-BOARD DIAGNOTICS II (DLC-OBD II) SHIELD
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE
DK GRN WIRE
DRL RELAY
EFI RELAY
ENGINE MAIN RELAY
HEATED OXYGEN SENSOR 1 CRANKSHAFT POSITION (CKP) SENSOR SHIELD
HEATED OXYGEN SENSOR 1 HEATED OXYGEN SENSOR 2
HEATED OXYGEN SENSOR 2
IDLE AIR CONTROL (IAC) VALVE
IGNITION COIL 1, IGNITION COIL 2,
INSTRUMENT CLUSTER ASSEMBLY
KNOCK SENSOR (KS) SHIELD
LEFT FRONT TURN/ PARK LAMP
LEFT STRUT TOWER)
MAIN RADIATOR FAN MOTOR (W/ A/C)
NOISE FILTER
PCM SHIELD
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT TURN/ PARK LAMP
SHIELD
ST RELAY
W/ ABS ONLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 3) -> ENGINE MAIN RELAY
Wiring diagram engine main relay (2 of 2)
ABS FUSE
ACCESSORY POWER RELAY JUNCTION BLOCK 1 (LEFT KICK PANEL)
ALT FUSE
ALT-S FUSE
AUXILIARY RADIATOR FAN MOTOR
BATTERY
BLK WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV) (W/ ABS)
CDS FUSE
DATA LINK CONNECTOR- ON-BOARD DIAGNOSTICS II (DLC-OBD II) STOP- LAMP SWITCH
DEF FUSE D/L FUSE
DEF RELAY
DOME FUSE
DOME TAIL RELAY NOISE FILTER
ECU-B FUSE
EFI FUSE
EFI RELAY
ENGINE MAIN RELAY
FAN 1 RELAY
FUSE
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT)
FUSE, RELAY BLOCK 2 (LEFT FRONT OF ENGINE COMPARTMENT)
FUSE, RELAY BLOCK 3 (RIGHT FRONT OF ENGINE COMPARTMENT)
FUSIBLE LINK (14 GA-
GENERATOR
GRN WIRE
HAZARD FUSE
HAZARD SWITCH
HEAD RELAY
HORN FUSE
HORN RELAY
HTR FUSE
HTR RELAY
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
MAIN FUSE
MULTI-FUNCTION ALARM MODULE
POWER FUSE
POWERTRAIN CONTROL MODULE (PCM)
RDI FUSE
RED WIRE
SHORT PIN
ST RELAY
STARTER
STOP FUSE OBD FUSE
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO JUNCTION BLOCK 1 (DIAGRAM 3 OF 3)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> ENGINE MAIN RELAY
