Chevrolet Prizm I (1997-2002) dome noise filter wiring diagram
This page shows the only wiring diagram for the component.dome noise filter, which is found in the car Chevrolet Prizm I (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
dome noise filter wiring diagram (1 of 1)
4 1 (W/A/C) (W/O A/C)
A/C COMPRESSOR CONTROL MODULE
ACCESSORY POWER RELAY
BLK WIRE
BLOWER MOTOR RESISTOR
BLOWER SPEED INSTRUMENT CLUSTER ASSEMBLY SELECTOR SWITCH
CRUISE CONTROL MODULE
CRUISE CONTROL SERVO
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR- ON-BOARD DIAGNOSTICS II (DLC-OBD II)
DIAGNOSTIC MODULE (SDM)
DOME NOISE FILTER
INFLATABLE RESTRAINT SENSING
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
JUNCTION BLOCK 1 (LEFT KICK PANEL)
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT WINDOW/ DOOR LOCK SWITCH
MULTI-FUNCTION ALARM MODULE
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
SUNROOF ACTUATOR
SUNROOF SUNROOF CONTROL MODULE
SWITCH ASSEMBLY
TO J/B 3 (DIAGRAM 3 OF 3)
TURN SIGNAL/ HEADLAMP SWITCH
TURN/ HAZARD FLASHER
W/ POWER LOCKS
W/ POWER WINDOWS
W/O POWER WINDOWS
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 3) -> DOME NOISE FILTER
