Chevrolet Prizm I (1997-2002) def relay Wiring diagrams
This page contains all the electrical diagrams for the component. def relay, in which he is found in the car Chevrolet Prizm I (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram def relay (1 of 3)
BLK WIRE
BLU WIRE
DEF FUSE
DEF RELAY
DEF- I/UP FUSE
DEFOGGER RELAY CONTROL
GAUGE FUSE
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON, START
IGNITION POWER
ILLUM LAMP
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (CENTER OF DASH)
MULTI- FUNCTION ALARM MODULE (MOUNTED TO JUNCTION BLOCK 2)
POWERTRAIN CONTROL MODULE (BEHIND FRONT OF CENTER CONSOLE) DEFOG SIGNAL
REAR DEFOGGER
REAR DEFOGGER INDICATOR
REAR DEFOGGER SWITCH
RED/BLU WIRE
TIMER/ENABLE DISABLE SIGNAL
WHT WIRE
WHT/BLK WIRE
Go to component -> Defogger circuit -> DEF RELAY
Wiring diagram def relay (2 of 3)
ABS FUSE
ACCESSORY POWER RELAY JUNCTION BLOCK 1 (LEFT KICK PANEL)
ALT FUSE
ALT-S FUSE
AUXILIARY RADIATOR FAN MOTOR
BATTERY
BLK WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV) (W/ ABS)
CDS FUSE
DATA LINK CONNECTOR- ON-BOARD DIAGNOSTICS II (DLC-OBD II) STOP- LAMP SWITCH
DEF FUSE D/L FUSE
DEF RELAY
DOME FUSE
DOME TAIL RELAY NOISE FILTER
ECU-B FUSE
EFI FUSE
EFI RELAY
ENGINE MAIN RELAY
FAN 1 RELAY
FUSE
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPT)
FUSE, RELAY BLOCK 2 (LEFT FRONT OF ENGINE COMPARTMENT)
FUSE, RELAY BLOCK 3 (RIGHT FRONT OF ENGINE COMPARTMENT)
FUSIBLE LINK (14 GA-
GENERATOR
GRN WIRE
HAZARD FUSE
HAZARD SWITCH
HEAD RELAY
HORN FUSE
HORN RELAY
HTR FUSE
HTR RELAY
INSTRUMENT CLUSTER ASSEMBLY
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
MAIN FUSE
MULTI-FUNCTION ALARM MODULE
POWER FUSE
POWERTRAIN CONTROL MODULE (PCM)
RDI FUSE
RED WIRE
SHORT PIN
ST RELAY
STARTER
STOP FUSE OBD FUSE
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO JUNCTION BLOCK 1 (DIAGRAM 3 OF 3)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> DEF RELAY
Wiring diagram def relay (3 of 3)
13 19 (4 A/T) (3 A/T)
A/C FAN 2 RELAY
ACCESSORY POWER RELAY
BACK-UP LAMP SWITCH PARK/ NEUTRAL POSITION (PNP) SWITCH
BLK WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE SHIFT LOCK CONTROL MODULE
CRUISE CONTROL MODULE
CRUISE CONTROL RELEASE SWITCH JUNCTION BLOCK 1 (LEFT KICK PANEL)
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE INSTRUMENT CLUSTER ASSEMBLY
DEF RELAY
ECU-IG FUSE
ENGINE MAIN RELAY WINDSHIELD WASHER PUMP
FAN 1 RELAY
FROM J/B 2 PIN 2 (DIAGRAM 1 OF 3)
FROM J/B 2 PIN 5 (DIAGRAM 1 OF 3)
FROM WIP FUSE (DIAGRAM 2 OF 3) GAUGE FUSE
FUSE, RELAY BLOCK 1 (LEFT FRONT OF ENGINE COMPARTMENT)
FUSE, RELAY BLOCK 2 (LEFT FRONT OF ENGINE COMPARTMENT)
FUSE, RELAY BOX 3 (RIGHT FRONT OF ENGINE COMPARTMENT)
GENERATOR VEHICLE SPEED SENSOR (VSS)
GRN WIRE
HAZARD SWITCH
HTR RELAY REAR DEFOGGER SWITCH
IGNITION SWITCH
JUNCTION BLOCK 1 (LEFT KICK PANEL)
JUNCTION BLOCK 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK 3 (CENTER OF DASH)
LOCK
M/T A/T
MULTI-FUNCTION ALARM MODULE
ORG/ WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH CLUTCH PEDAL POSITION (CPP) INTERRUPT SWITCH
POWERTRAIN CONTROL MODULE (PCM) (A/T ONLY)
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
ST FUSE
TO CIG FUSE (DIAGRAM 3 OF 3)
TO GAUGE FUSE (DIAGRAM 2 OF 3)
TO IGN FUSE (DIAGRAM 3 OF 3)
W/ CRUISE CONTROL
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WIP FUSE TURN FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> DEF RELAY
