Courtesy lamp circuit, crew cab with overhead roof console for Chevrolet Pickup K3500 (1988-2000)

BATTERY JUNCTION BLOCK (RIGHT REAR ENGINE COMPARTMENT, AT COWL) BLK WIRE CARGO LAMP CARGO LAMP SWITCH CONVENIENCE CENTER COURTESY SWITCH CREW CAB ONLY CREW CAB, SUBURBAN, UTILITY W/OVERHEAD ROOF CONSOLE CTSY FUSE FRONT DOME LAMP FUSE BLOCK HOT AT ALL TIMES IN-LINE FUSE LEFT FRONT DOOR JAMB SWITCH ORG/ WIRE ORG/BLK WIRE OVERHEAD ROOF CONSOLE LAMPS PANEL DIMMER SWITCH REAR DOME LAMP RED WIRE RIGHT FRONT DOOR JAMB SWITCH SUBURBAN/YUKON BASE UNDERHOOD REEL LAMP WHT WIRE
