6.5l vin f, manual a/c circuit for Chevrolet Pickup K2500 (1988-2000)

1 2 3 4 5 6 7 8 9 10 ILLUMINATION GROUND A/C DISABLE RECIRC SIGNAL IGNITION A/C COMP FUSE A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (IN UNDERHOOD FUSE CENTER) A/C COMPRESSOR CYCLING SWITCH (IN LOW PRESSURE LINE, ON ACCUMULATOR) A/C CTRL A/C ENABLE A/C HIGH PRESSURE CUTOUT SWITCH (ON A/C COMPRESSOR) A/C LOW PRESSURE CUTOUT SWITCH (ON A/C COMPRESSOR) AIR TEMP DR SIGNAL MODE SIGNAL A/C SWITCH BATTERY IGNITION GROUND DEFOGGER ELEMENT BLK WIRE BLOWER FUSE 3 BLOWER MOTOR BLOWER RESISTOR (UNDER RIGHT SIDE OF DASH, ON HEATER HOUSING) BLOWER SWITCH BRN WIRE DIODE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT MODE DOOR MOTOR (ON FRONT A/C-HEATER HOUSING) FRONT TEMPERATURE DOOR MOTOR (ON FRONT A/C-HEATER HOUSING) FUSE BLOCK GRY WIRE HEATER AND A/C CONTROL MODULE HIGH BLOWER RELAY (UNDER DASH ON TOP OF HEATER-A/C HOUSING) HOT AT ALL TIMES UNDERHOOD FUSE BLOCK HOT IN RUN HOT IN RUN OR START HTR A/C FUSE 12 IGN E FUSE LT BLU WIRE LT GRN WIRE OFF LO ORG/ WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) PPL REAR DEFOGGER SYSTEM RECIRCULATION DOOR MOTOR (UNDER DASH ON HEATER- A/C HOUSING) RED WIRE TAN WIRE WHT WIRE YEL WIRE
