Chevrolet Pickup K2500 (1988-2000) fog lamp on indicator Wiring diagram
This page shows the only wiring diagram for the component.fog lamp on indicator, which is found in the car Chevrolet Pickup K2500 (1988-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog lamp on indicator (1 of 1)
BLK WIRE
BRN WIRE
CONVENIENCE CENTER
DK BLU WIRE
FOG LAMP ON INDICATOR
FOG LAMP RELAY (BEHIND LEFT SIDE OF I/P)
FOG LAMP SWITCH SOLID STATE SWITCH
FUSE BLOCK
GRN WIRE
GRY WIRE
HEADLAMP DIMMER SWITCH
HEADLIGHT SWITCH ASSEMBLY
HI BEAM INDICATOR
HI LO
HOT AT ALL TIMES
HOT AT ALL TIMES ACC-BATT CIRCUIT BREAKER
ILLUM LAMP
LEFT LOW BEAM HEAD- LAMP
LT GRN WIRE
LT INSTRUMENT CLUSTER
LT LT
OFF
OFF HEAD HEAD PARK
ORG/BLK WIRE
PARK
PNL LPS FUSE
PPL
PPL PPL
RIGHT FOG LAMP LEFT FOG LAMP
RIGHT HIGH BEAM HEAD- LAMP LEFT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP
TAN WIRE
VARIABLE VOLTAGE W/ HEADLIGHT SWITCH IN PARK OR HEAD, RHEOSTAT ADJUSTED
WHT WIRE
YEL WIRE
