4.3l (vin w), cruise control circuit for Chevrolet Pickup K1500 (1988-1999)

4000 PULSES/MILE CRUISE STATUS BLK WIRE BLK/WHT WIRE BLU WIRE BRAKE FUSE 18 STOP/HAZ FUSE 1 BRN WIRE BRN/WHT WIRE CLUTCH PEDAL SWITCH (TOP OF CLUTCH PEDAL) CRUISE CONTROL MODULE (LEFT REAR OF ENGINE COMPARTMENT) CRUISE CONTROL SWITCH CRUISE FUSE 6 CRUISE ON INPUT SET/COAST INPUT RESUME/ACCEL INPUT CRUISE STATUS VEHICLE SPEED INPUT DISENGAGE INPUT GROUND IGNITION BRAKE APPLIED INPUT DK BLU WIRE DK GRN/WHT WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN I/P FUSE BLOCK LT BLU/BLK WIRE LT GRN/BLK WIRE M/T A/T OFF OR 379 451 ORG/ WIRE PPL PPL/WHT WIRE R/A S/C DK STOPLAMP SWITCH (TOP OF BRAKE PEDAL) VEHICLE CONTROL MODULE (VCM) (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF TRANSMISSION) VSS RETURN VSS SIGNAL WHT WIRE
