Chevrolet Pickup K1500 (1988-1999) stoplamp sw input speed sensor input Wiring diagrams
This page contains all the electrical diagrams for the component. stoplamp sw input speed sensor input, in which he is found in the car Chevrolet Pickup K1500 (1988-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stoplamp sw input speed sensor input (1 of 2)
BRAKE FUSE 18
BRAKE PRESSURE MODULATOR VALVE: ANTI-LOCK BRAKES SYSTEM
BRN WIRE
CLUTCH PEDAL SWITCH (TOP OF CLUTCH PEDAL)
CRUISE CONTROL SWITCH
CRUISE FUSE 6
CRUISE ON INPUT S/C SIGNAL R/A SIGNAL
DK BLU WIRE
FUSE BLOCK
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES STOP/HAZ FUSE 1
HOT IN RUN
LT GRN/BLK WIRE
M/T A/T
OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (UNDER RIGHT SIDE OF I/P)
PPL
PPL STOPLAMP/CLUTCH SW IN
PPL/WHT WIRE
R/A
S/C
STOPLAMP SW INPUT SPEED SENSOR INPUT
TCC/ STOPLAMP SWITCH (TOP OF BRAKE PEDAL)
VEHICLE SPEED SENSOR
VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT SIDE OF I/P)
WHT WIRE
Go to component -> 6.5l (vin f), cruise control circuit -> STOPLAMP SW INPUT SPEED SENSOR INPUT
