Chevrolet Pickup K1500 (1988-1999) rear window defogger grid Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger grid, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger grid (1 of 1)
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH)
HEATED MIRROR RELAY (IN UNDERHOOD FUSE/RELAY CENTER)
HEATER AND A/C CONTROL SWITCH
HOT IN RUN
HOT IN RUN OR START
HTR A/C FUSE 12
I/P FUSE BLOCK
LEFT CARGO DOOR CONTACTOR
LEFT HEATED MIRROR
LEFT OUTSIDE REAR VIEW MIRROR
LEFT REAR CARGO DOOR DEFOGGER GRID
MIRRORS FUSE
NCA WIRE
ORG/ WIRE
PICK-UP W/ EXTENDED OR CREW CAB
PPL
REAR DEFOGGER SWITCH
REAR WINDOW DEFOGGER GRID
RIGHT CARGO DOOR CONTACTOR
RIGHT HEATED MIRROR
RIGHT REAR CARGO DOOR DEFOGGER GRID
RR DEFOG FUSE
SOLID STATE TIME DELAY RELAY
SUBURBAN/UTILITY W/ LIFTGATE
SUBURBAN/UTILITY W/O LIFTGATE
UNDERHOOD FUSE/RELAY CENTER
W/ HEATED MIRRORS
Go to component -> Defogger circuit -> REAR WINDOW DEFOGGER GRID
