Chevrolet Pickup K1500 (1988-1999) rear door door lock lock switch control module Wiring diagram
This page shows the only wiring diagram for the component.rear door door lock lock switch control module, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear door door lock lock switch control module (1 of 1)
AUDIO ALARM MODULE
AUX/PWR FUSE 7
AUXILIARY POWER CONNECTOR
BLK WIRE
BRN WIRE
CIG LTR FUSE 13
CIGAR LIGHTER
CONVENIENCE CENTER
CRANK FUSE 8
DATA LINK CONNECTOR
DOOR REMOTE CONTROL LOCK DOOR LOCK RELAY RECEIVER
FROM UNDERHOOD FUSE-RELAY CENTER (DIAGRAM 1 OF 4)
I/P FUSE BLOCK
IGNITION SWITCH
INSTRUMENT CLUSTER
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT RIGHT FRONT POWER DOOR LOCK DOOR LOCK AMPLIFIER SWITCH SWITCH RELAY
LEFT POWER SEAT
LOCK LOCK OFF OFF
LOCK OFF
M/T A/T
MAXI FUSE 5
MAXI FUSE 6
MAXI FUSE 7
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER WDO CIRCUIT BREAKER
PPL
PWR-ACCY CIRCUIT BREAKER
RADIO
RADIO BATT FUSE 19
RADIO FUSE 17
REAR DOOR DOOR LOCK LOCK SWITCH CONTROL MODULE
REAR WINDOW LOCKOUT SWITCH (4-DR)
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT POWER LUMBAR SEAT SWITCH
RIGHT FRONT POWER POWER WINDOW WINDOW MASTER SWITCH SWITCH (2 DR, UTILITY)
RR WIPER FUSE 23 WIPER FUSE 11
RUN WIRE
STARTER RELAY UNDERHOOD FUSE-RELAY CENTER
STOP/HAZ FUSE 1
SUBURBAN ONLY
SUBURBAN/ UTILITY PICKUP
T CASE FUSE 2
TCC/STOPLAMP SWITCH
TO I/P FUSE BLOCK (DIAGRAM 4 OF 4)
TO SECURITY/ STRG FUSE 21 (DIAGRAM 4 OF 4)
TO UNDERHOOD FUSE-RELAY CENTER (DIAGRAM 3 OF 4)
TRANS FUSE 20
TRANS- MISSION
TRANSFER CASE CONTROL MODULE
TURN/ HAZARD SWITCH
UNDERHOOD FUSE-RELAY CENTER
W/BENCH SEAT
W/O BENCH SEAT
WHT WIRE
WINDSHIELD RADIO WIPER MOTOR MODULE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> REAR DOOR DOOR LOCK LOCK SWITCH CONTROL MODULE
