Chevrolet Pickup K1500 (1988-1999) overhead console reading lamps Wiring diagram
This page shows the only wiring diagram for the component.overhead console reading lamps, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead console reading lamps (1 of 1)
BLK WIRE
COURTESY LAMPS CIRCUIT
CTSY FUSE 3
FRONT DOME/ READING LAMPS
HEADLAMP, PANEL DIMMER SWITCH COURTESY LAMPS
HOT AT ALL TIMES
I/P FUSE BLOCK
INT LAMP OUTPUT
ORG/ WIRE
OVERHEAD CONSOLE READING LAMPS
REAR DOME READING LAMPS
REMOTE CONTROL DOOR LOCK RECEIVER (W/RKE) (BEHIND CENTER OF DASH)
WHT WIRE
Go to component -> Overhead console lamps circuit -> OVERHEAD CONSOLE READING LAMPS
