Chevrolet Pickup K1500 (1988-1999) low coolant level indicator module Wiring diagram
This page shows the only wiring diagram for the component.low coolant level indicator module, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low coolant level indicator module (1 of 1)
AUDIO ALARM MODULE
AUXILIARY COOLING FAN MOTOR
BLK WIRE
BLK/GRY WIRE
BTSI GROUND
CIGAR LIGHTER
CONVENIENCE CENTER
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS MODULE
FROM CONVENIENCE CENTER (DIAGRAM 3 OF 4)
FRONT WINDSHIELD WIPER/ WASHER PUMP MOTOR
HEADLAMP AND PANEL DIMMER SWITCH
HEATER AND A/C CONTROL SWITCH
HVAC CONTROL MODULE
I/P COMPARTMENT ASHTRAY LAMP LAMP
IGNITION STEERING SWITCH COLUMN GROUND GROUND
INFLATABLE CARGO RESTRAINT LAMP I/P MODULE SWITCH ENABLE (PICKUP) SWITCH
LEFT BATTERY
LEFT FOG LAMP
LEFT FRONT DOOR JAMB SWITCH
LEFT FRONT PARK/ TURN LAMP
LEFT HIGH/ LOW BEAM HEADLAMP
LEFT HORN
LEFT LEFT HIGH LOW BEAM BEAM HEADLAMP HEADLAMP
LOW COOLANT LEVEL INDICATOR MODULE
POWER POWER OUTLET OUTLET
RADIO
REAR WINDOW WASHER PUMP MOTOR
REAR WINDOW WIPER/ WASHER SWITCH
REAR WINDOW WIPER/ WASHER SWITCH (SUBURBAN/ UTILITY)
RIGHT FOG LAMP
RIGHT FRONT DOOR JAMB SWITCH
RIGHT FRONT PARK/ TURN LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH/ LOW BEAM HEADLAMP
RIGHT HORN
RIGHT LOW BEAM HEADLAMP
SPARE
TRANSFER CASE CONTROL MODULE
TRANSFER CASE SELECT SWITCH
TURN/ HAZARD FLASHER
UNCOATED
W/ DUAL HORNS
WINDSHIELD WIPER MOTOR MODULE
Go to component -> Ground distribution circuit (1 of 5) -> LOW COOLANT LEVEL INDICATOR MODULE
