Chevrolet Pickup K1500 (1988-1999) glow glow plug 3 plug 5 Wiring diagram
This page shows the only wiring diagram for the component.glow glow plug 3 plug 5, which is found in the car Chevrolet Pickup K1500 (1988-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glow glow plug 3 plug 5 (1 of 1)
"SERV ENG SOON" IND ENGINE SHUTOFF SOL OUT EGR SOL OUTPUT
"SERV THROTTLE SOON" IND EGR VALVE SOL PUTPUT
A/C ENABLE PCM GND PCM GND
A/C SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE BRAKE CONTROL MODULE (EBCM) (ON LEFT SIDE OF ENGINE COMPT)
ENG-I FUSE
EXHAUST GAS RECIRCULATION (EGR) VENT SOLENOID (TOP LEFT REAR OF ENGINE)
EXHAUST GAS RECIRCULATION EGR SOLENOID (TOP LEFT REAR OF ENGINE)
FUEL HEATER (TOP REAR OF ENGINE)
FUEL SOL MODULE (5 VREF)
FUSIBLE LINK
FUSIBLE LINKS
GLOW GLOW PLUG 3 PLUG 5
GLOW PLUG 1
GLOW PLUG 2
GLOW PLUG 4
GLOW PLUG 6
GLOW PLUG 7
GLOW PLUG 8
GLOW PLUG OUTPUT
GLOW PLUG RELAY (TOP LEFT REAR OF ENGINE)
GRD
GROUND
GRY WIRE
HOT AT ALL TIMES FUSIBLE LINK
HOT IN RUN OR START
LT GRN WIRE
ORG/ WIRE
PNK IGN WIRE
PNK PNK 439 439 IGNITION IGNITION WIRE
PNK PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
PPL
RED WIRE
RELAY CTRL
SIGNAL
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE-RELAY CENTER
WASTEGATE SOL ENGINE SHUTOFF SOL OUT
WASTEGATE SOLENOID (TOP LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.5l (vin s)s (4 of 4) -> GLOW GLOW PLUG 3 PLUG 5
